-20~120º C Flange Installation Air Turbine Flow Meter
Package size per unit product 200.00cm * 30.00cm * 30.00cm Gross weight per unit product 20.000kg Why choose us: 1. 23 y
Basic Info
Model NO. | HKD |
Main Application | Water, Diesel Fuel, Fuel Oil, Nature Gas, Corrosive Liquid/Gas, Liquid |
Size | DN6-DN200 |
Sensor | Tube/Flange |
Application | Fluid Measurement |
Type | Turbine Flow Meter |
Measuring Media | Liquid |
Measuring Principle | Mechanics |
Measurement Object | Closed Pipeline |
Certification | CE, ISO |
Material | 304/316L |
Pressure Level | 6.3MPa or Less |
Temperature Range | -20~120ºC |
Installation Method | Flange, Thread, Clamp |
Power Supply | Battery, 24VDC |
Output | 4-20mA, Pulse Hart, RS485 |
Straight Pipe Section | Minimum 10dn After 5dn |
Transport Package | Wooden Box |
Specification | make to order |
Trademark | Vacorda |
Origin | Sichuan China |
HS Code | 90261000 |
Production Capacity | 2000pieces/Month |
Packaging & Delivery
Package size per unit product 200.00cm * 30.00cm * 30.00cm Gross weight per unit product 20.000kgProduct Description
Why choose us:1. 23 years of instrumentation equipment production experience2. Product support OEM, ODM, export to more than 100 countries3. The company area 20,000 square meters, and 150+ orders per month4. Provide email, skype, whatsapp provide 24-hour one-on-one technical support service onlineFlowmeter product series
Product Description
Turbine flow meter liquid flows through the turbine housing causing an internal rotor to spin. As the rotor spins, an electrical signal is generated in the pickup coil. This signal is converted into engineering units (liters, cubic meters, gallons etc.) on the local display where is applicable. Optional accessory modules can be used to export the signal to other equipment. It has the features, such as high accuracy, good repeatability, convenient installation/maintenance, simple structure etc.
Product Parameters:
(1) Pressure: | PN16-PN63 |
(2)Output signal: | 4-20mA/RS485/HART |
(3) Medium: | Clean liquid,air |
(4)Operating temperature: | -20 ~ +120 °C |
(5)Measuring Range: | <1200m3/h |
(6) Material: | 304,316L,321 |
(7)Nominal diameter: | DN6-DN200 |
(8) Viscosity : | 5~400mpa.s |
(9) Accuracy: | 0.5,1.0,1.5 |
(10)Protection class: | IP65 |
Flowmeter Details
If you have any questions, please send us inquiry and contact us directly, we will provide you with professional help.
